Vibrating Screen Introduce

Vibrating Screen are used to separate materials into various sizes for further processing, or for end use.It is widely used in plastics, abrasive, chemical, pharmaceutical, building materials and industry.

Application:

The vibrating screen is a kind of sieving equipment of international advanced level, developed by our company on the basis of carrying on the advantages of traditional screens and absorbing the outstanding technology from abroad. It is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydropower, transportation, chemical industry, smelting and so on.

Features and Benefits:

The vibrating screen features long flowing line, many screening specifications, strong violent vibration force, high screening efficiency, small vibrating noises, firm and durable construction, convenient maintenance and safe operation.

Operating Principle:

The vibrating screen adjusts the amplitude by tube-shaped violent vibration screen of eccentric shaft and eccentric blocks. The body moves like a circle, in order to make the materials screened.

Vibrating Screen Specification :

Type	Screen Spec .(mm)	Layers	Sieve Pore (mm)	Max. Feed Size (mm)	Capacity (t/h)	Power (KW)	Screen area (m2)	Weight Excluding Motor (t)
2YA1237	1200×3700	2	3-50	200	7.5-80	5.5	4.44	2.34
3YA1237	1200×3700	3	3-50	200	7.5-80	7.5	4.44	3.05
2YA1548	1500×4800	2	5-50	400	50-208	15	7.2	5.33
3YA1548	1500×4800	3	5-50	400	50-250	15	7.2	6.07
2YA1848	1800×4800	2	5-80	400	50-260	18.5	8.64	6.65
3YA1848	1800×4800	3	5-80	400	50-300	18.5	8.64	6.93
2YA1860	1800×6000	2	5-80	400	50-350	22	10.8	7.52
3YA1860	1800×6000	3	5-80	400	50-350	22	10.8	7.72
4YA1860	1800×6000	4	5-80	400	50-350	22	10.8	8.70
2YA2160	2100×6000	2	5-100	400	100-500	30	12.6	10.2
3YA2160	2100×6000	3	5-100	400	100-500	30	12.6	10.5
4YA2160	2100×6000	4	5-100	400	100-500	30	12.6	10.8
2YA2460	2400×6000	2	5-150	400	150-700	37	14.4	10.4
3YA2460	2400×6000	3	5-150	400	150-700	37	14.4	10.8

Note: This specification is just reference, any changes are subject to the products.
